TP-Link InSight S445. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Turret. Minimum illumination: 0.005 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 100°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7″). Detect distance: 64 m, Observe distance: 27 m, Recognize distance: 13 m
2 laos
2 laos
People & Vehicle Analytics
Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.
Human & Vehicle Classification
Distinguish humans and vehicles from other objects and receive more accurate event notifications.
Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
| Vendor | TP-LINK |
|---|---|
| Alarm In | 1 |
| Alarm Out | 1 |
| RJ45 | 1 |
| Model | InSight S445S |
| Camera design | Bullet |
| Network Camera Type | Fixed/Outdoor |
| Resolution | 4 Mega Pixel |
| Focal Length | 2.8mm |
| Sensor size | 1/1.79” Progressive Scan CMOS |
| Lens Mount | M12 |
| Min. Illumination | 0.0005 Lux |
| Electronic Shutter Speed | 1/3 to 1/10000 s |
| Supports card capacities up to | 512GB |
| Power options | 12V/PoE |
| Power supply requirements | • 12V DC ± 5%, Max. 15.6 W, 5.5 mm Coaxial Power Plug • PoE: 802.3at, Class 4, Max. 17.9 W |
| Environment | Outdoor |
| Operating temperature range | -30 °C to 60 °C |
| Included Accessories | • Quick Start Guide |
| Colour | White |
| Dimensions | Φ111 × 81.4 mm |
| Unit Calculated Volume | 0.002988 cubm |
| Product Net Weight | 0.55 kg |
| Unit Calculated Weight | 0.82 kg |
| Summary | TP-Link InSight S445. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Turret. Minimum illumination: 0.005 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 100°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Detect distance: 64 m, Observe distance: 27 m, Recognize distance: 13 m |
| Connectivity technology | Wired |
| Dynamic range | 120 dB |
| Infrared (IR) cut-off filter | Yes |
| People counting function | Yes |
| Placement supported | Indoor & outdoor |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
| Form factor | Turret |
| Housing material | Metal |
| International Protection (IP) code | IP67 |
| Mounting type | Ceiling/wall |
| Product colour | White |
| Angle of rotation | 360 ° |
| Camera shutter speed | 1/3 – 1/10000 s |
| Lens viewing angle, diagonal | 118 ° |
| Lens viewing angle, horizontal | 100 ° |
| Lens viewing angle, vertical | 54 ° |
| Minimum illumination | 0.005 lx |
| Number of Privacy masking areas | 4 |
| Pan range | 0 – 360 ° |
| Tilt angle range | 0 – 85 ° |
| Optical sensor size | 1/2.7 " |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Detect distance | 64 m |
| Fixed focal length | 2.8 mm |
| Identify distance | 6 m |
| Maximum aperture number | 1.6 |
| Number of lenses | 1 |
| Observe distance | 27 m |
| Recognize distance | 13 m |
| Infra-red wavelength | 850 nm |
| LED type | IR/White |
| Night vision | Yes |
| Night vision distance | 30 m |
| Back Light Compensation (BLC) | Yes |
| Bit rate | Main Stream: 256 Kbps – 6 Mbps; Sub-Stream: 64 Kbps – 512 Kbps |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Highlight Compensation (HLC) | Yes |
| Maximum resolution | 2688 x 1520 pixels |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Region of Interest (ROI) encoding | Yes |
| Smart IR | Yes |
| Supported graphics resolutions | 1280 x 720 (HD 720)/1920 x 1080 (HD 1080)/2048 x 1280/2304 x 1296/2560 x 1440/2688 x 1520/320 x 240/352 x 288/640 x 480 (VGA)/704 x 576 |
| Total megapixels | 4 MP |
| Video compression formats | H.264/H.264+/H.265/H.265+ |
| Video streaming | Yes |
| Audio system | 2-way |
| Built-in microphone | Yes |
| Built-in speaker(s) | Yes |
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP |
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 512 GB |
| Ethernet LAN (RJ-45) ports | 1 |
| Active tampering alarm | Yes |
| Digest authentication | Yes |
| HTTPS encryption | Yes |
| Intelligent Video Surveillance (IVS) system features | Abandoned object/Abnormal sound detection/Human detection/Intrusion/Line crossing detection/Region entrance detection/Region exiting detection/Scene change/Vehicle detection |
| IP address filtering | Yes |
| Password protection | Yes |
| Privacy protection | Yes |
| Video motion detection | Yes |
| Cloud-managed | Yes |
| Reset button | Yes |
| Web browser | Yes |
| DC output voltage | 12 |
| Power source type | DC,PoE |
| Operating relative humidity (H-H) | 0 – 95 % |
| Operating temperature (T-T) | -30 – 60 °C |
| Storage relative humidity (H-H) | 0 – 95 % |
| Storage temperature (T-T) | -40 – 60 °C |
| Diameter | 111 mm |
| Height | 83.7 mm |
| Weight | 480 g |
| Compliance certificates | BSMI/CE/Federal Communications Commission (FCC)/Industry Canada (IC)/KC/VCCI |
| Manual | Yes |
| Mounting kit | Yes |
| Number of cameras | 1 |
| Units per Shipping Box | 1 |
| Manufacturer Code | INSIGHT S445S(2.8MM) |
| ELKO Code | 1451220 |
| Warranty | 36 |
