Axis 02131-001. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Black, Form factor: Bullet. Minimum illumination: 0.16 lx, Camera shutter speed: 1/19000 – 1/5 s. Sensor type: CMOS, Optical sensor size: 25.4 / 2.9 mm (1 / 2.9″). Night vision distance: 20 m, LED type: IR, Infra-red wavelength: 855 nm
Laost otsas
Laost otsas
Ideal for tough environments and rough weather, AXIS M2035-LE delivers HDTV in 1080p. With a deep learning processing unit, it enables unique opportunities for analytics based on deep learning on the edge. AXIS Object Analytics offers detection and classification of humans, vehicles, and types of vehicles. And Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis devices on your network. Available in two lens alternatives, this IK08-rated camera offers flexible and cost-efficient installation including PoE. Edge-to-edge technology allows for smart pairing with Axis speakers. Plus, a spacious, sealed back box ensures secure cable management.
| Vendor | AXIS |
|---|---|
| MicroSD Card Slot | 1 |
| RJ45 | 1 |
| Model | M2035-LE |
| Camera design | Bullet |
| Network Camera Type | Fixed/HDTV/Megapixel/Outdoor |
| Resolution | 2 Mega Pixel |
| Focal Length | 3.2 mm, F1.4 |
| IR Illumination | Yes |
| Sensor size | 1/2.9” progressive scan RGB CMOS |
| Min. Illumination | 0.03 Lux |
| Electronic Shutter Speed | 1/19000 s to 1/5 s |
| Power options | PoE |
| Power supply requirements | Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3 |
| Power consumption | 5 Watts |
| Environment | Outdoor |
| Operating temperature range | -30 °C to 50 °C |
| Included Accessories | Installation guide, Windows® |
| Colour | Black |
| Dimensions | 170x101mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.002484 cubm |
| Product Net Weight | 0.491 kg |
| Unit Calculated Weight | 0.7 kg |
| Summary | Axis 02131-001. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Black, Form factor: Bullet. Minimum illumination: 0.16 lx, Camera shutter speed: 1/19000 – 1/5 s. Sensor type: CMOS, Optical sensor size: 25.4 / 2.9 mm (1 / 2.9"). Night vision distance: 20 m, LED type: IR, Infra-red wavelength: 855 nm |
| Certification | CISPR 24, CISPR 35, EN 55032 Class A, EN 55035, |
| Connectivity technology | Wired |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Languages support | English/French/German/Italian/Japanese/Korean/Polish/Portuguese/Russian/Simplified Chinese/Spanish/Traditional Chinese |
| Number of languages | 12 |
| Placement supported | Indoor & outdoor |
| PTZ modes | Digital PTZ |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
| Form factor | Bullet |
| Housing material | Aluminium/Plastic |
| IK code | IK08 |
| International Protection (IP) code | IP66, IP67 |
| Mounting type | Ceiling/wall |
| Product colour | Black |
| Camera shutter speed | 1/19000 – 1/5 s |
| Minimum illumination | 0.16 lx |
| Number of sensors | 1 |
| Optical sensor size | 1/2.9 " |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Number of lenses | 1 |
| Zoom capability | Yes |
| Infra-red wavelength | 855 nm |
| LED type | IR |
| Night vision | Yes |
| Night vision distance | 20 m |
| Bit rate control | Variable Bit Rate (VBR) |
| Flip & mirror | Yes |
| Frame rate | 30 fps |
| Image quality adjustment | Brightness/Contrast/Sharpness |
| Maximum resolution | 1920 x 1080 pixels |
| Privacy masking | Yes |
| Supported graphics resolutions | 1280 x 960/1920 x 1080 (HD 1080) |
| Supported video modes | 1080p |
| Text caption overlay | Yes |
| Total megapixels | 2 MP |
| Video compression formats | H.264/H.265/M-JPEG |
| Video recording | Yes |
| Bluetooth | No |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.1x/IEEE 802.3af/IEEE 802.3at |
| Quality of Service (QoS) support | Yes |
| Supported network protocols | IPv4, IPv6 USGv6, HTTP, HTTPSb , HTTP/2, TLSb , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, DHCPv4/v6, SOCKS, SSH, LLDP, MQTT v3.1.1 |
| Wi-Fi | No |
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash)/MicroSDHC/MicroSDXC |
| Flash memory | 512 MB |
| Internal memory | 1024 MB |
| Ethernet LAN (RJ-45) ports | 1 |
| Active tampering alarm | Yes |
| Alert notification type | |
| Digest authentication | Yes |
| HTTPS encryption | Yes |
| IP address filtering | Yes |
| Password protection | Yes |
| Pixel counter | Yes |
| Security algorithms | 256-bit AES-XTS/EAP-TLS |
| Video motion detection | Yes |
| Power consumption (max) | 12.9 W |
| Power consumption (typical) | 5 W |
| Power source type | PoE |
| Operating relative humidity (H-H) | 10 – 100 % |
| Operating temperature (T-T) | -30 – 50 °C |
| Storage relative humidity (H-H) | 5 – 95 % |
| Storage temperature (T-T) | -40 – 65 °C |
| Diameter | 101 mm |
| Length | 170 mm |
| Weight | 491 g |
| Manual | Yes |
| Number of cameras | 1 |
| Doesn't contain | BFR/PVC |
| Manufacturer Code | 02131-001 |
| ELKO Code | 1376303 |
| Warranty | 60 |
