Axis M1135-E. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: Black, Form factor: Box. Minimum illumination: 0.02 lx, Lens viewing angle, horizontal: 90°, Lens viewing angle, vertical: 49°. Sensor type: CMOS, Optical sensor size: 25.4 / 3 mm (1 / 3″). Focal length range: 3 – 10.5 mm
Laost otsas
Laost otsas
AXIS M1135-E is a compact, outdoor-ready network camera that delivers excellent image quality in 2 MP resolution. Designed as a visible deterrent, it helps discourage trespassing, antisocial or criminal behavior. It offers flexible, low-cost installation making it ideal for various industrial or commercial surveillance situations, such as warehouses, storage or delivery areas.
More bang for your buck
This affordable Axis M-line camera offers one-way audio allowing you to record video with sound. And, with a video streaming indicator, it’s easy to check that the video is up and running. Featuring Axis Zipstream with support for both H.264 and H.265 video compression it significantly reduces bandwidth and storage requirements without compromising image quality. Thanks to support for PoE and redundant DC power, you get flexible installation and your data is safeguarded in the event of a power outage.
Furthermore, it offers enhanced security functionality to prevent unauthorized access and safeguard your system. Signed firmware and secure boot ensures only authorized firmware is installed and that the firmware hasn’t been compromised.
Sharp images even in low light
AXIS M1135-E offers 2 MP resolution at up to 30 fps and delivers excellent video quality even in low light conditions. It features Axis Lightfinder for images in true colors even in low light and with Axis Forensic WDR you get clarity even when there’s both dark and light areas in the scene. Furthermore, it offers a CS-mount with interchangeable lenses, so you can easily change lens and ensure you capture the exact images you need. Use our lens calculator to select a lens that meets your specific requirements.
Designed for deterrence
This robust, outdoor-ready camera has you covered both day and night – outside in the cold, heat, rain or sun, or inside your office or store. It comes enclosed in an IP66-, IK10- and NEMA 4X-rated casing to protect against water, corrosion, dust and impacts. AXIS M1135-E sends a powerful message of deterrence to potential offenders to let them know you’re watching. It provides a clearly visible, fixed angle of view, making it easy to see exactly where the camera’s pointing and allowing you to record both audio and video in a precisely defined area.
| Vendor | AXIS |
|---|---|
| RJ45 | 1 |
| Terminal block | 1 |
| Camera design | Bullet |
| Network Camera Type | Fixed/HDTV/Megapixel |
| Sensor size | RGB CMOS 1/3" |
| Min. Illumination | 0.15 Lux |
| Electronic Shutter Speed | 1/33500 to 2 s |
| Operating temperature range | -25 °C to 50 °C |
| Dimensions | 240 x 143 x 372 mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.01404 cubm |
| Product Net Weight | 1.8 kg |
| Unit Calculated Weight | 2.6 kg |
| Summary | Axis M1135-E. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: Black, Form factor: Box. Minimum illumination: 0.02 lx, Lens viewing angle, horizontal: 90°, Lens viewing angle, vertical: 49°. Sensor type: CMOS, Optical sensor size: 25.4 / 3 mm (1 / 3"). Focal length range: 3 – 10.5 mm |
| Certification | EN 55032 A, EN 61000-3-2, EN 61000-3-3, EN 55024, |
| Connectivity technology | Wired |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Languages support | English/French/German/Italian/Japanese/Korean/Polish/Portuguese/Russian/Simplified Chinese/Spanish/Traditional Chinese |
| Number of languages | 12 |
| Placement supported | Outdoor |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
| Form factor | Box |
| Housing material | Polycarbonate (PC) |
| IK code | IK10 |
| International Protection (IP) code | IP66 |
| Mounting type | Wall |
| Product colour | Black |
| Camera shutter speed | 1/33500 – 1/5 s |
| Lens viewing angle, horizontal | 90 ° |
| Lens viewing angle, vertical | 49 ° |
| Minimum illumination | 0.02 lx |
| Number of sensors | 1 |
| Optical sensor size | 1/3 " |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Focal length range | 3 – 10.5 mm |
| Number of lenses | 1 |
| Bit rate control | Variable Bit Rate (VBR) |
| Frame rate | 30 fps |
| Maximum resolution | 1920 x 1080 pixels |
| Supported graphics resolutions | 160 x 90/1920 x 1080 (HD 1080) |
| Supported video modes | 1080p |
| Total megapixels | 2 MP |
| Video compression formats | AVC/H.264/H.265/HEVC/M-JPEG |
| Video streaming | Yes |
| Audio detection | Yes |
| Audio formats supported | AAC-LC/ADPCM/LPCM/PCM |
| Built-in microphone | Yes |
| Sample rate | 48 kHz |
| Voice codecs | G.711/G.726/OPUS |
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.1x/IEEE 802.3af/IEEE 802.3at |
| Quality of Service (QoS) support | Yes |
| Supported network protocols | IPv4, IPv6 USGv6, HTTP, HTTPS , SSL/TLS , QoS L3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP |
| Wi-Fi | No |
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash)/MicroSDHC/MicroSDXC |
| Flash memory | 512 MB |
| Internal memory | 1024 MB |
| DC-in jack | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Microphone in | Yes |
| HTTPS encryption | Yes |
| IP address filtering | Yes |
| Password protection | Yes |
| Security algorithms | EAP-TLS |
| Video motion detection | Yes |
| Power consumption (max) | 6.49 W |
| Power consumption (Power over Ethernet (PoE)) | 6.49 W |
| Power consumption (typical) | 3.8 W |
| Power source type | DC,PoE |
| Operating relative humidity (H-H) | 10 – 100 % |
| Operating temperature (T-T) | -25 – 50 °C |
| Storage relative humidity (H-H) | 5 – 95 % |
| Storage temperature (T-T) | -40 – 65 °C |
| Depth | 143 mm |
| Length | 372 mm |
| Weight | 1800 g |
| Width | 240 mm |
| Manual | Yes |
| Mounting kit | Yes |
| Number of cameras | 1 |
| Harmonized System (HS) code | 85258900 |
| Manufacturer Code | 01772-001 |
| ELKO Code | 1285206 |
| Warranty | 60 |
