Dahua Technology WizSense HDW2849TM-S-IL. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/Wall/Pole, Product colour: Black, Form factor: Dome. Angle of rotation: 360°, Tilt angle range: 0 – 78°, Pan range: 0 – 360°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7″). Night vision distance: 30 m, LED type: IR
14 laos
14 laos
8MP Smart Dual Light Fixed-focal Eyeball WizSense Network Camera
| Kaal | 0,48 kg |
|---|---|
| Vendor | DAHUA |
| RJ45 | 1 |
| Model | DHI-IPC-HDW2849TM-S-IL-0280B-B |
| Camera design | Eyeball |
| Network Camera Type | HDTV/Megapixel/Outdoor |
| Resolution | 8 Mega Pixel |
| IR Illumination | Yes |
| Sensor size | 1/2.7" |
| Microphone | Built-in |
| Lens Mount | M22 |
| Min. Illumination | 0.0008 Lux |
| Effective pixels | 3840 (H) × 2160 (V) |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Supports card capacities up to | 256GB |
| Power options | 12V/PoE |
| Power supply requirements | Basic: 2.6 W (12 VDC); 3.3 W (PoE) |
| Power consumption | 5.9 Watts |
| Environment | Outdoor |
| Operating temperature range | –40 °C to +55 °C |
| Colour | Black |
| Dimensions | 99.1 mm × Φ121.9 mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.002254 cubm |
| Product Net Weight | 0.48 kg |
| Unit Calculated Weight | 0.651 kg |
| Form factor | Dome |
| International Protection (IP) code | IP67 |
| Mounting type | Ceiling/Wall/Pole |
| Product colour | Black |
| Protection features | Dust resistant |
| Built-in light | Yes |
| Certification | CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive; 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Connectivity technology | Wired |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Placement supported | Outdoor |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
| Angle of rotation | 360 ° |
| Camera shutter speed | 1/3 -1/100000 s |
| Camera shutter type | Electronic |
| Pan range | 0 – 360 ° |
| Tilt angle range | 0 – 78 ° |
| White balance | Auto/Manual/Natural/Outdoor/Regional custom/Street lamp |
| Number of sensors | 1 |
| Optical sensor size | 1/2.7 " |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Minimum aperture number | 1.6 |
| Number of lenses | 2.8 |
| LED type | IR |
| Night vision | Yes |
| Night vision distance | 30 m |
| Back Light Compensation (BLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Flip & mirror | Yes |
| Gain control type | Auto/Manual |
| Highlight Compensation (HLC) | Yes |
| Maximum resolution | 3840 x 2160 pixels |
| Privacy masking | Yes |
| Region of Interest (ROI) encoding | Yes |
| Supported graphics resolutions | 1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2048 x 1536 (QXGA)/2304 x 1296/2688 x 1520/2880 x 1620/3072 x 1728/3072 x 2048/352 x 240/352 x 288/3840 x 2160/640 x 480 (VGA)/704 x 480/704 x 576 |
| Total megapixels | 8 MP |
| Video compression formats | H.264/H.264+/H.264B/H.264H/H.265/H.265+/M-JPEG |
| Video streaming | Yes |
| Audio formats supported | G.711 µ-law/G.711 A-law/G.726/PCM |
| Signal-to-Noise Ratio (SNR) | 56 dB |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Number of users | 20 user(s) |
| Quality of Service (QoS) support | Yes |
| Streaming method | Multicast |
| Supported network protocols | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Boujour |
| Internal memory | 256 MB |
| ROM capacity | 128 MB |
| Ethernet LAN (RJ-45) ports | 1 |
| Active tampering alarm | Yes |
| Intelligent Video Surveillance (IVS) system features | Intrusion/Tripwire |
| Video motion detection | Yes |
| Management software | Smart PSS; DSS; DMSS |
| Web browser | Yes |
| DC output voltage | 12 |
| Power consumption (typical) | 2.6 W |
| Power source type | DC,PoC |
| Operating relative humidity (H-H) | 0 – 95 % |
| Operating temperature (T-T) | -40 – 55 °C |
| Storage temperature (T-T) | -40 – 60 °C |
| Mobile operating systems supported | Android/iOS |
| Diameter | 121.9 mm |
| Weight | 480 g |
| Width | 99.1 mm |
| Number of cameras | 1 |
| Summary | Dahua Technology WizSense HDW2849TM-S-IL. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/Wall/Pole, Product colour: Black, Form factor: Dome. Angle of rotation: 360°, Tilt angle range: 0 – 78°, Pan range: 0 – 360°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Night vision distance: 30 m, LED type: IR |
| Package weight | 620 g |
| Manufacturer Code | HDW2849TM-S-IL-0280B-B |
| ELKO Code | 1413075 |
| Warranty | 36 |
