6MP Smart Dual Light Fixed-focal Dome WizSense Network Camera
>1/2.7" CMOS image sensor, low luminance, and high definition image.
>Outputs max. 6 MP (3288×1850) @20 fps, and supports 2688×1520 (2688 × 1520) @25/30 fps.
>H.265 codec, high compression rate, ultra-low bit rate.
>Built-in warm light and IR LED, the max. IR distance is 30 m and the max. warm light distance is 30 m.
>ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
>Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
>Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).
>Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
>Supports max. 256 G Micro SD card; built in Mic.
>12 VDC/PoE power supply, easy for installation.
>IP67, IK10 protection.
>SMD Plus
> Focal Length 2.8 mm; Field of View 112°
| Kaal | 0,34 kg |
|---|---|
| Vendor | DAHUA |
| Model | IPC-HDBW2649E-S-IL-0280B-B |
| Camera design | Dome |
| Network Camera Type | HDTV/Megapixel/Outdoor |
| Resolution | 6 Mega Pixel |
| Focal Length | 2.8 mm; 3.6 mm |
| IR Illumination | Yes |
| Sensor size | 1/2.7" CMOS |
| Microphone | Built-in |
| Lens Mount | M12 |
| Min. Illumination | 0.0007 Lux |
| Effective pixels | 3288 (H) × 1850 (V) |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Power supply requirements | 12 VDC; PoE |
| Power consumption | 8.2 Watts |
| Environment | Outdoor |
| Operating temperature range | –40 °C to +60 °C |
| Colour | White |
| Dimensions | 81.0 mm × Φ109.9 mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.003352 cubm |
| Product Net Weight | 0.34 kg |
| Unit Calculated Weight | 0.49 kg |
| Form factor | Dome |
| IK code | IK10 |
| International Protection (IP) code | IP67 |
| Product colour | White |
| Connectivity technology | Wired |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
| Camera shutter speed | 1/3 s–1/100,000 s s |
| Field of view (FOV) angle | 112 ° |
| Minimum illumination | 0.0007 lx |
| Number of sensors | 1 |
| Optical sensor size | 1/2.7" " |
| Sensor type | CMOS |
| Fixed focal length | 2.8 mm |
| B/W night vision distance | 30 m |
| LED type | IR |
| Night vision | Yes |
| 3D NR (Noise Reduction) | Yes |
| Back Light Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | Yes |
| Maximum resolution | 3288×1850 pixels |
| Total megapixels | 6 MP |
| Built-in microphone | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
| Ethernet LAN (RJ-45) ports | 1 |
| DC output voltage | 12 |
| Power consumption (typical) | 6.8 W |
| Power source type | DC,PoE |
| Operating temperature (T-T) | –40 °C to +60 °C °C |
| Diameter | 109.9 mm |
| Height | 81 mm |
| Weight | 340 g |
| Lens mount interface | M12 |
| Manufacturer Code | DH-IPC-HDBW2649E-S-IL-0280B |
| ELKO Code | 1441436 |
| Warranty | 36 |
