Dahua Technology IPC-HDW2649T-ZS-IL-27135. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Turret. Sensor type: CMOS. Maximum resolution: 3288 x 1850 pixels, Total megapixels: 6 MP. Power source type: DC, PoE
5 laos
5 laos
Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI
chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast
act on defined targets. Based on Dahua’s advanced technologies, WizSense provides intelligent, simple and
inclusive products and solutions.
| Kaal | 0,69 kg |
|---|---|
| Vendor | DAHUA |
| Model | IPC-HDW2649T-ZS-IL-27135 |
| Camera design | Eyeball |
| Network Camera Type | HDTV/Megapixel/Outdoor |
| Resolution | 6 Mega Pixel |
| Focal Length | 2.7 mm–13.5 mm |
| IR Illumination | Yes |
| Sensor size | 1/2.7" CMOS |
| Microphone | Built-in |
| Min. Illumination | 0.0007 Lux |
| Effective pixels | 3288 (H) × 1850 (V) |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Supports card capacities up to | 256GB |
| Power supply requirements | 12 VDC/PoE |
| Power consumption | 8.4 Watts |
| Environment | Outdoor |
| Operating temperature range | –30 °C to +60 °C |
| Colour | White |
| Dimensions | 108.3 mm × Φ122.0 mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.003243 cubm |
| Product Net Weight | 0.69 kg |
| Unit Calculated Weight | 0.86 kg |
| Form factor | Turret |
| International Protection (IP) code | IP67 |
| Product colour | White |
| Connectivity technology | Wired |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
| Camera shutter speed | 1/3 s–1/100,000 s |
| Minimum illumination | 0.0007 lx |
| Number of sensors | 1 |
| Optical sensor size | 1/2.7 " |
| Sensor type | CMOS |
| Focal length range | 2.7-13.5 mm |
| B/W night vision distance | 40 m |
| LED type | IR |
| Night vision | Yes |
| 3D NR (Noise Reduction) | Yes |
| Back Light Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | Yes |
| Maximum resolution | 3288 x 1850 pixels |
| Total megapixels | 6 MP |
| Built-in microphone | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
| DC output voltage | 12 |
| Power consumption (typical) | 8.4 W |
| Power source type | DC,PoE |
| Operating temperature (T-T) | -30 – 60 °C |
| Diameter | 122 mm |
| Height | 108.3 mm |
| Weight | 690 g |
| Lens type | Varifocal |
| Summary | Dahua Technology IPC-HDW2649T-ZS-IL-27135. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Turret. Sensor type: CMOS. Maximum resolution: 3288 x 1850 pixels, Total megapixels: 6 MP. Power source type: DC, PoE |
| Mounting type | Ceiling |
| Placement supported | Indoor & outdoor |
| Number of lenses | 1 |
| Bluetooth | No |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Built-in HDD | No |
| Cloud-managed | Yes |
| Number of cameras | 1 |
| Long Description | Dahua Technology IPC-HDW2649T-ZS-IL-27135. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Turret. Sensor type: CMOS. Maximum resolution: 3288 x 1850 pixels, Total megapixels: 6 MP. Power source type: DC, PoE |
| Bullet Points | > 6-MP 1/2.7" CMOS image sensor, low luminance, and high definition image> Outputs max. 6MP (3288 × 1850)@20 fps, and supports 2688×1520 (2688 × 1520)@25/30 fpsH.265 codec, high compression rate, ultra-low bit rateBuilt-in multi-core light, the max. IR distance is 40 m and the max. warm light distance is 40 mROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environmentsRotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenesIntelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human)Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detectionSupports max. 256 G Micro SD card; built in Mic12 VDC/PoE power supplyIP67 protectionSMD Plus |
| Width | 122 mm |
| Depth | 122 mm |
| Storage temperature (T-T) | -30 – 60 °C |
| Operating relative humidity (H-H) | 0 – 95 % |
| Storage relative humidity (H-H) | 0 – 95 % |
| Package weight | 860 g |
| Manufacturer Code | IPC-HDW2649T-ZS-IL-27135 |
| ELKO Code | 1441441 |
| Warranty | 36 |
