> 6-MP 1/2.7" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 6 MP (3288 1850)@25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in multi-core light, the max. IR distance is 30 m and the max. warm light distance is 30 m.
> ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human), stay detection, loitering detection; face detection (full image).
> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card; built-in Mic.
> 12 VDC/PoE power supply.
> IP67 protection.
> SMD 4.0.
> Supports AI SSA.
> SMD area can be set in warm light areas that support triggering alarms.
> Focal Length 2.8 mm. Field of View 110°
| Kaal | 0,61 kg |
|---|---|
| Vendor | DAHUA |
| Alarm In | 1 |
| Alarm Out | 1 |
| Audio-In | 1 |
| Audio-Out | 1 |
| RJ45 | 1 |
| Camera design | Bullet |
| Network Camera Type | HDTV/Megapixel/Outdoor |
| Resolution | 6 Mega Pixel |
| Focal Length | 2.8 mm |
| Sensor size | 1/2.7" |
| Microphone | Built-in |
| Lens Mount | M12 |
| Min. Illumination | 0.0005 Lux |
| Effective pixels | 3288 (H) × 1850 (V) |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Supports card capacities up to | 512GB |
| Power options | 12V/PoE |
| Power consumption | 8 Watts |
| Environment | Outdoor |
| Operating temperature range | –40 °C to +60 °C |
| Colour | Black |
| Dimensions | 192.7 mm 70.5 mm 66.4 mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.002299 cubm |
| Product Net Weight | 0.61 kg |
| Unit Calculated Weight | 0.79 kg |
| Form factor | Bullet |
| Product colour | Black |
| Number of effective pixels (H x V) | 3288 (H) × 1850 (V) pixels |
| Optical sensor size | 1/2.7" " |
| Sensor type | CMOS |
| Fixed focus | Yes |
| Focal length range | 2.8 mm; 3.6 mm mm |
| Total megapixels | 6 MP |
| Ethernet LAN (RJ-45) ports | 1 |
| Power consumption (max) | 8 W |
| Power consumption (Power over Ethernet (PoE)) | 10 W |
| Power consumption (typical) | 3.7 W |
| Operating temperature (T-T) | –40 °C to +60 °C °C |
| Depth | 70.5 mm |
| Height | 66.4 mm |
| Weight | 610 g |
| Width | 192.7 mm |
| Audio input | 1 |
| Audio output | 1 |
| Power source | 12 VDC/PoE (802.3af) |
| Suitable for outdoor use | Yes |
| Manufacturer Code | IPC-HFW3649E-AS-IL-0280B-B |
| ELKO Code | 1441454 |
| Warranty | 36 |
