Dahua Technology Pro DH-IPC-HFW5541T-ASE. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Bullet. Angle of rotation: 360°, Lens viewing angle, horizontal: 84°, Lens viewing angle, vertical: 58°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7″). Detect distance: 80 m, Observe distance: 32 m, Recognize distance: 16 m
30 laos
30 laos
Dahua AI series products adopt the most advanced AI technologies, including deep learning algorithms that primarily target people and vehicles, which provides higher flexibility and accuracy for end-users. This enables the Dahua AI series to offer various advanced applications such as Face Recognition, ANPR, Metadata, People Counting, traffic data statistics, etc.The complete lineup of Dahua AI includes network (PTZ) cameras, network video recorders, servers, and platform management products. Beyond seeing the world, the power of AI allows devices to perceive the environment and understand the world in a better way
| Vendor | DAHUA |
|---|---|
| Alarm In | 1 |
| Alarm Out | 1 |
| Audio-In | 1 |
| Audio-Out | 1 |
| RJ45 | 1 |
| Model | IPC-HFW5541T-ASE-0280B-S3 |
| Camera design | Bullet |
| Network Camera Type | HDTV/Megapixel/Outdoor |
| Resolution | 5 Mega Pixel |
| Focal Length | 2.8 mm |
| IR Illumination | Yes |
| Sensor size | 1/2.7” |
| Lens Mount | M12 |
| Min. Illumination | 0.0005 Lux |
| Effective pixels | 2960 (H) × 1668 (V) |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Supports card capacities up to | 512GB |
| Power options | 12V/PoE |
| Power supply requirements | ePoE / PoE / 12VDC power, 9.8W max |
| Power consumption | 9.8 Watts |
| Environment | Outdoor |
| Operating temperature range | -40°C~+60°C |
| Colour | White |
| Dimensions | 244.1 × 79.0 × 75.9 mm |
| Units per Shipping Box | 10 |
| Unit Calculated Volume | 0.004742 cubm |
| Product Net Weight | 0.82 kg |
| Unit Calculated Weight | 1.33 kg |
| Summary | Dahua Technology Pro DH-IPC-HFW5541T-ASE. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Bullet. Angle of rotation: 360°, Lens viewing angle, horizontal: 84°, Lens viewing angle, vertical: 58°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Detect distance: 80 m, Observe distance: 32 m, Recognize distance: 16 m |
| Alarm input/output | Yes |
| Certification | CE-LVD:EN60950-1 |
| Connectivity technology | Wired |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Placement supported | Outdoor |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
| Form factor | Bullet |
| Housing material | Metal |
| International Protection (IP) code | IP67 |
| Mounting type | Ceiling/wall |
| Product colour | White |
| Angle of rotation | 360 ° |
| Camera pan control | Yes |
| Camera shutter speed | 1/3 – 1/100000 s |
| Camera shutter type | Electronic/Mechanical |
| Camera tilt control | Yes |
| Lens viewing angle, horizontal | 84 ° |
| Lens viewing angle, vertical | 58 ° |
| Pan range | 0 – 360 ° |
| Tilt angle range | 0 – 90 ° |
| White balance | Auto/Manual/Natural/Outdoor |
| Number of sensors | 1 |
| Optical sensor size | 1/2.7 " |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Closest focusing distance | 1.6 m |
| Detect distance | 80 m |
| Fixed focal length | 3.6 mm |
| Identify distance | 8 m |
| Maximum aperture number | 1.6 |
| Number of lenses | 1 |
| Observe distance | 32 m |
| Recognize distance | 16 m |
| LED type | IR |
| Night vision | Yes |
| Night vision distance | 78 m |
| Number of illumination LEDs | 4 |
| Back Light Compensation (BLC) | Yes |
| Bit rate | 32- 8192Kbps, 19- 8192Kbps |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Flip & mirror | Yes |
| Frame rate | 30 fps |
| Gain control type | Auto/Manual |
| Highlight Compensation (HLC) | Yes |
| Maximum resolution | 2592 x 1944 pixels |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Privacy masking | Yes |
| Supported graphics resolutions | 1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2304 x 1296/2592 x 1944/2688 x 1520/352 x 240/352 x 288/640 x 480 (VGA)/704 x 480/704 x 576 |
| Supported video modes | 1080p/720p |
| Total megapixels | 5 MP |
| Video compression formats | H.264/H.264+/H.265/H.265+/M-JPEG |
| Video streaming | Yes |
| Audio formats supported | AAC |
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Voice codecs | G.711a/G.711Mu/G.723/G.726 |
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.3af |
| Number of users | 20 user(s) |
| Quality of Service (QoS) support | Yes |
| Streaming method | Multicast/Unicast |
| Supported network protocols | HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP;SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; SNMP;QoS; UPnP;NTP |
| Wi-Fi | No |
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Internal memory | 512 MB |
| Maximum memory card size | 256 GB |
| ROM capacity | 128 MB |
| Ethernet LAN (RJ-45) ports | 1 |
| Intelligent Video Surveillance (IVS) system features | Intrusion/People counting/Scene change/Tripwire |
| Mirror | Yes |
| Video motion detection | Yes |
| Web-based management | Yes |
| DC output voltage | 12 |
| Power consumption (max) | 7.1 W |
| Power consumption (Power over Ethernet (PoE)) | 8.4 W |
| Power source type | DC,PoE |
| Operating relative humidity (H-H) | 10 – 95 % |
| Operating temperature (T-T) | -30 – 60 °C |
| Storage relative humidity (H-H) | 10 – 95 % |
| Storage temperature (T-T) | 5 – 40 °C |
| Mobile operating systems supported | Android/iOS |
| Depth | 75.9 mm |
| Length | 244.1 mm |
| Weight | 815 g |
| Width | 79 mm |
| Package weight | 1080 g |
| Number of cameras | 1 |
| CnCode | 85258900 |
| Manufacturer Code | IPC-HFW5541T-ASE-0280B-S3 |
| ELKO Code | 1404932 |
| Warranty | 36 |
