Dahua Technology Pro IPC-HDW5442TMP-ASE-0280B. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Dome. Minimum illumination: 0.002 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 113°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8″), Number of effective pixels (H x V): 2688 x 1520 pixels. Detect distance: 58 m, Observe distance: 23 m, Recognize distance: 12 m
20 laos
20 laos
Pro AI series contains Face Detection, Perimeter Protection and People
Counting functions.Powered by deep-learning Artificial Intelligence algo-
rithms, significantly improved accuracy. Meanwhile, the series features
starlight and smart IR technology. This series fully protected from dust
and water, certified to IP67 standard.
Face Detection
Face Detection is a software application that automatically captures
faces from within a digital image or a video frame from a video source.
Dahua cameras use advanced deep learning algorithms and are trained
by a large number of face data sources, enabling the camera to locate
faces quickly and accurately from the video source and capture facial
images.
Perimeter Protection
Dahua’s Perimeter Protection functions significantly improved accu-
racy. Perimeter Protection reduces false alarms and decreases pixel
count requirements for object detection. Perimeter Protection features
custom tripwires based on object type for automation in limited access
areas such as pedestrian or vehicle-only zones. This combination of
advanced AI analytics and real-time alerts to a desktop or to a mobile
client reduces system requirements and resources resulting in greater
surveillance system efficiency.
People Counting
People Counting function uses advanced image processing technology
to capture depth information from within images. The camera pairs this
information with deep learning algorithms to analyze and detect human
bodies and track target objects in real time. The camera provides statis-
tics for separate individuals’ entrance and exit with up to 95% counting
accuracy.
Protection(IP67, wide voltage)
The camera allows for ±30% input voltage tolerance, suitable for the
most unstable conditions for outdoor applications. Its 6KV lightning rat-
ing provides effective protection for both the camera and its structure
against lightning. Subjected and certified to rigorous dust and immer-
sion tests (IP67) , the camera is the choice for installation in even the
most unforgiving environmen
| Vendor | DAHUA |
|---|---|
| Alarm In | 1 |
| Alarm Out | 1 |
| Audio-In | 1 |
| Audio-Out | 1 |
| MicroSD Card Slot | 1 |
| Model | IPC-HDW5442TM-ASE-0280B-S3 |
| Camera design | Eyeball |
| Network Camera Type | Fixed/Outdoor |
| Resolution | 4 Mega Pixel |
| Focal Length | 2.8mm |
| IR Illumination | Yes |
| Sensor size | 1/1.8”CMOS |
| Microphone | Built-in |
| Min. Illumination | 0.0004 Lux |
| Supports card capacities up to | 256GB |
| Power options | 12V/PoE |
| Power supply requirements | ePoE / PoE / 12VDC |
| Power consumption | 7.2 Watts |
| Environment | Outdoor |
| Operating temperature range | -40°C~+60°C |
| Colour | White |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.002957 cubm |
| Product Net Weight | 0.5 kg |
| Unit Calculated Weight | 0.75 kg |
| Summary | Dahua Technology Pro IPC-HDW5442TMP-ASE-0280B. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Dome. Minimum illumination: 0.002 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 113°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"), Number of effective pixels (H x V): 2688 x 1520 pixels. Detect distance: 58 m, Observe distance: 23 m, Recognize distance: 12 m |
| Form factor | Dome |
| Housing material | Metal |
| International Protection (IP) code | IP67 |
| Mounting type | Ceiling |
| Product colour | White |
| Certification | CE-LVD: EN60950-1 |
| Connectivity technology | Wired |
| Day/night mode | Yes |
| Dynamic range | 140 dB |
| Placement supported | Indoor & outdoor |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
| Adjustment shutter speed | Auto/Manual |
| Angle of rotation | 360 ° |
| Camera shutter speed | 1/3 -1/100000 s |
| Camera shutter type | Electronic |
| Lens viewing angle, horizontal | 113 ° |
| Lens viewing angle, vertical | 60 ° |
| Minimum illumination | 0.002 lx |
| Pan range | 0 – 360 ° |
| Tilt angle range | 0 – 78 ° |
| White balance | Auto/Lamp/Manual/Natural/Outdoor |
| Number of effective pixels (H x V) | 2688 x 1520 pixels |
| Number of sensors | 1 |
| Optical sensor size | 1/1.8 " |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Detect distance | 58 m |
| Focal length range | 2.8 mm |
| Identify distance | 6 m |
| Maximum aperture number | 1.6 |
| Number of lenses | 1 |
| Observe distance | 23 m |
| Recognize distance | 12 m |
| LED type | IR |
| Night vision | Yes |
| Night vision distance | 50 m |
| Number of illumination LEDs | 2 |
| Analog signal format system | PAL |
| Back Light Compensation (BLC) | Yes |
| Bit rate | 32 Kbps-8192 Kbps |
| Bit rate control | Constant Bit Rate (CBR),Variable Bit Rate (VBR) |
| Flip & mirror | Yes |
| Frame rate | 30 fps |
| Gain control type | Auto/Manual |
| Highlight Compensation (HLC) | Yes |
| Maximum resolution | 2688 x 1520 pixels |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Privacy masking | Yes |
| Region of Interest (ROI) encoding | Yes |
| Smart IR | Yes |
| Supported graphics resolutions | 1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2304 x 1296/2560 x 1440/2688 x 1520/352 x 240/352 x 288/640 x 480 (VGA)/720 x 480/720 x 576 |
| Total megapixels | 4 MP |
| Video compression formats | H.264/H.264+/H.265/H.265+ |
| Video streaming | Yes |
| Built-in microphone | Yes |
| Voice codecs | AAC/G.711a/G.711Mu/G.723/G.726 |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.3af |
| Number of users | 20 user(s) |
| Quality of Service (QoS) support | Yes |
| Streaming method | Multicast/Unicast |
| Supported network protocols | IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP |
| Compatible memory cards | MicroSD (TransFlash) |
| Internal memory | 512 MB |
| Maximum memory card size | 256 GB |
| ROM capacity | 128 MB |
| Ethernet LAN (RJ-45) ports | 1 |
| Intelligent Video Surveillance (IVS) system features | Face detection/Heat map/Intrusion/People counting/Tripwire |
| Mirror | Yes |
| Video motion detection | Yes |
| Management software | Smart PSS, DSS, DMSS |
| Web browser | Yes |
| DC output voltage | 12 |
| Power consumption (typical) | 7.2 W |
| Power source type | DC,PoE |
| Operating relative humidity (H-H) | 0 – 95 % |
| Operating temperature (T-T) | -40 – 60 °C |
| Storage temperature (T-T) | -40 – 60 °C |
| Mobile operating systems supported | Android/iOS |
| Diameter | 106 mm |
| Height | 99.2 mm |
| Weight | 550 g |
| Package weight | 710 g |
| Number of cameras | 1 |
| Manufacturer Code | HDW5442TM-ASE-0280B-S3 |
| ELKO Code | 1396729 |
| Warranty | 36 |
