Dahua Technology WizSense DH-IPC-HDBW3441R-AS-P. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Assorted colours, Form factor: Dome. Minimum illumination: 0.0005 lx, Angle of rotation: 355°, Lens viewing angle, horizontal: 170°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7″), Number of effective pixels (H x V): 2880 x 1620 pixels. Fixed focal length: 2.1 mm, Closest focusing distance: 0.6 m
5 laos
5 laos
Series Overview
With advanced deep learning algorithm, Dahua WizSense 3 Series
network camera supports intelligent functions, such as perimeter
protection and smart motion detection. With starlight technology, this
series camera provides a better image effect in the condition of low
illuminance.
Launched by Dahua Technology, WizSense is a series of AI products and
solutions that adopt independent AI chip and deep learning algorithm.
It focuses on human and vehicle with high accuracy, enabling users to
fast act on defined targets. Based on Dahua’s advanced technologies,
WizSense provides intelligent, simple and inclusive products and
solutions.
Functions
EPTZ
With advanced target detection and tracking algorithms, Dahua EPTZ
technology can simultaneously zoom in and track multiple humans and
vehicles that trigger alarms. It provides rich details and a panoramic
view at the same time.
SMD 3.0
With intelligent algorithm, Dahua Smart Motion Detection technology
can categorize the targets that trigger motion detection and filter the
motion detection alarm triggered by non-concerned targets to realize
effective and accurate alarm.
Smart H.265+ & Smart H.264+
With advanced scene-adaptive rate control algorithm, Dahua smart
encoding technology realizes the higher encoding efficiency than H.265
and H.264, provides high-quality video, and reduces the cost of storage
and transmission.
Perimeter Protection
With deep learning algorithm, Dahua Perimeter Protection technology
can recognize human and vehicle accurately. In restricted area (such
as pedestrian area and vehicle area), the false alarms of intelligent
detection based on target type (such as tripwire, intrusion) are largely
reduced.
| Kaal | 0,5 kg |
|---|---|
| Vendor | DAHUA |
| Alarm In | 1 |
| Alarm Out | 1 |
| Audio-In | 1 |
| Audio-Out | 1 |
| MicroSD Card Slot | 1 |
| RJ45 | 1 |
| Model | IPC-HDBW3441R-AS-P-0210B |
| Camera design | Dome |
| Network Camera Type | Fixed Dome/Outdoor |
| Resolution | 4 Mega Pixel |
| Focal Length | 2.1 mm |
| IR Illumination | Yes |
| Sensor size | 1/2.7" CMOS |
| Microphone | Built-in |
| Lens Mount | M12 |
| Min. Illumination | 0.001 Lux |
| Supports card capacities up to | 256GB |
| Power options | 12V/PoE |
| Power supply requirements | PoE / 12VDC power |
| Power consumption | 7.7 Watts |
| Environment | Outdoor |
| Operating temperature range | -40°C~+60°C |
| Dimensions | 94 mm × Φ122.0 mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.005776 cubm |
| Product Net Weight | 0.5 kg |
| Unit Calculated Weight | 0.775 kg |
| Summary | Dahua Technology WizSense DH-IPC-HDBW3441R-AS-P. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Assorted colours, Form factor: Dome. Minimum illumination: 0.0005 lx, Angle of rotation: 355°, Lens viewing angle, horizontal: 170°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"), Number of effective pixels (H x V): 2880 x 1620 pixels. Fixed focal length: 2.1 mm, Closest focusing distance: 0.6 m |
| Alarm input/output | Yes |
| Connectivity technology | Wired |
| Day/night mode | Yes |
| Dynamic range | 120 dB |
| Placement supported | Indoor & outdoor |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
| Fog proof | Yes |
| Form factor | Dome |
| Housing material | Metal |
| IK code | IK10 |
| International Protection (IP) code | IP67 |
| LED indicators | Yes |
| Mounting type | Ceiling/wall |
| Product colour | Assorted colours |
| Weatherproof | Yes |
| Adjustment shutter speed | Auto/Manual |
| Angle of rotation | 355 ° |
| Camera shutter speed | 1/3 s-1/100,000 s |
| Camera shutter type | Electronic |
| Camera tilt control | No |
| Lens viewing angle, diagonal | 175 ° |
| Lens viewing angle, horizontal | 170 ° |
| Lens viewing angle, vertical | 75 ° |
| Minimum illumination | 0.0005 lx |
| Pan range | 0 – 355 ° |
| Tilt angle range | 0 – 80 ° |
| White balance | Auto/Custom modes/Manual/Natural/Outdoor/Street lamp |
| Number of effective pixels (H x V) | 2880 x 1620 pixels |
| Number of sensors | 1 |
| Optical sensor size | 1/2.7 " |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Closest focusing distance | 0.6 m |
| Fixed focal length | 2.1 mm |
| Maximum aperture number | 2 |
| Number of lenses | 1 |
| Night vision | Yes |
| Back Light Compensation (BLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Gain control type | Auto/Manual |
| Highlight Compensation (HLC) | Yes |
| Maximum resolution | 2880 x 1620 pixels |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Region of Interest (ROI) encoding | Yes |
| Total megapixels | 4 MP |
| Video compression formats | H.264/H.264B/H.265/M-JPEG |
| Video formats supported | H.264+/H.265+ |
| Bluetooth | No |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.1x |
| Number of users | 20 user(s) |
| Streaming method | Multicast/Unicast |
| Supported network protocols | IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
| Wi-Fi | No |
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Internal memory | 512 MB |
| Maximum memory card size | 256 GB |
| ROM capacity | 128 MB |
| Ethernet LAN (RJ-45) ports | 1 |
| Behavior analysis | Intrusion detection,Line crossing detection |
| Web browser | Yes |
| Web-based management | Yes |
| DC output voltage | 12 |
| Power consumption (max) | 6.4 W |
| Power consumption (Power over Ethernet (PoE)) | 7.7 W |
| Power consumption (typical) | 3.2 W |
| Power source type | DC,PoE |
| Operating relative humidity (H-H) | 0 – 95 % |
| Operating temperature (T-T) | -40 – 60 °C |
| Storage temperature (T-T) | -40 – 60 °C |
| Mobile operating systems supported | Android/iOS |
| Diameter | 122 mm |
| Height | 94 mm |
| Weight | 500 g |
| Package weight | 770 g |
| Number of cameras | 1 |
| Manufacturer Code | IPC-HDBW3441R-AS-P-0210B |
| ELKO Code | 1389498 |
| Warranty | 36 |
