> 2MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
> Outputs 2MP (1920 × 1080)@25/30 fps
> H.265 codec, high compression ration, ultra-low bit rate
> Built-in IR LED, max IR distance: 30 m
> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
> Rotation mode, DWDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
> Intelligent detection: Intrusion, tripwire
> Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnected, IP conflict, illegal access, voltage detection
> Supports max. 256 GB Micro SD card, built-in Mic
> 12V DC/PoE power support
> IP67 protection
> Focal Length: 2.8 mm
> Field of View: 110°
| Kaal | 0,39 kg |
|---|---|
| Warranty | 36 |
| RJ45 | 1 |
| Model | DH-IPC-HDW2230T-AS-S2 |
| Camera design | Eyeball |
| Network Camera Type | HDTV/Megapixel/Outdoor |
| Resolution | 2 Mega Pixel |
| Focal Length | 2.8 mm; 3.6 mm |
| IR Illumination | Yes |
| Sensor size | 1/2.7" |
| Microphone | Built-in |
| Min. Illumination | 0.0005 Lux |
| Effective pixels | 1920 (H) × 1080 (V) |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100000 s |
| Supports card capacities up to | 256GB |
| Power options | 12V/PoE |
| Power supply requirements | 12V DC/PoE (802.3af) |
| Environment | Outdoor |
| Operating temperature range | –40 °C to +60 °C |
| Dimensions | 100.9 mm × Φ109.9 mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.003243 cubm |
| Product Net Weight | 0.39 kg |
| Unit Calculated Weight | 0.54 kg |
| Form factor | Eyeball |
| Product colour | White |
| Connectivity technology | Wired |
| Camera shutter speed | 1/3 s–1/100000 s s |
| Camera shutter type | Electronic/Mechanical |
| Effective sensor resolution | 2 pixels |
| Optical sensor size | 1/2.7” " |
| Sensor type | CMOS |
| Fixed focal length | 2.8 mm |
| B/W night vision distance | 30 m |
| Night vision | Yes |
| Built-in microphone | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
| Ethernet LAN (RJ-45) ports | 1 |
| DC output voltage | 12 |
| Power over Ethernet (PoE) | Yes |
| Diameter | 109.9 mm |
| Height | 100.9 mm |
| Lens mount interface | M12 |
| Suitable for outdoor use | Yes |
| Adjustment shutter speed | Auto/Manual |
