Dahua Technology LM22-J200. Display diagonal: 54.6 cm (21.5″), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting. Product colour: Black
18 laos
18 laos
The Dahua J200 series CCTV monitor operates 24/7, delivering low power consumption and an extended lifespan. With its impressive 5 ms response time and a 100 Hz refresh rate, this monitor ensures that your images and videos are displayed without ghosting or blurring. Additionally, it is highly compatible with Dahua backend security devices, making it an excellent choice for various desktop displays and security video monitoring walls.
| Vendor | DAHUA |
|---|---|
| Summary | Dahua Technology LM22-J200. Display diagonal: 54.6 cm (21.5"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting. Product colour: Black |
| Backlight type | Edge LED |
| Colour depth | 8 bit |
| Colour gamut standard | NTSC |
| Contrast ratio (typical) | 1000:1 |
| Display brightness (typical) | 250 cd/m² |
| Display diagonal | 21.5 " |
| Display diagonal (metric) | 56 cm |
| Display resolution | 1920 x 1080 pixels |
| Display technology | LED |
| Haze rate | 25 % |
| HD type | Full HD |
| LED backlight | Yes |
| Maximum refresh rate | 100 Hz |
| Native aspect ratio | 16:9 |
| NTSC coverage (typical) | 50 % |
| Panel type | IPS |
| Pixel pitch | 0.24795 x 0.24795 mm |
| Response time | 5 ms |
| Screen shape | Flat |
| Surface hardness | 3H |
| Touchscreen | No |
| Viewable size, horizontal | 476.064 mm |
| Viewable size, vertical | 267.786 mm |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
| Flicker-free technology | Yes |
| Operating hours (hours/days) | 24/7 |
| Built-in camera | No |
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 4 W |
| Detachable stand | Yes |
| Feet colour | Black |
| Frameless design | Yes |
| Front bezel colour | Black |
| Product colour | Black |
| Audio output | Yes |
| Built-in USB hub | No |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| VGA (D-Sub) ports quantity | 1 |
| Height adjustment | No |
| LED indicators | Yes |
| Panel mounting interface | 75 x 75 mm |
| Plug and Play | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -6 – 27 ° |
| VESA mounting | Yes |
| Wall mountable | Yes |
| AC adapter output voltage | 12 V |
| Current rating | 2 A |
| Energy consumption (SDR) per 1000 hours | 10 kWh |
| Energy efficiency class (SDR) | C |
| Energy efficiency scale | A to G |
| Power consumption (max) | 13.6 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 10.4 W |
| Power supply type | External |
| Operating relative humidity (H-H) | 10 – 85 % |
| Operating temperature (T-T) | 0 – 40 °C |
| Storage relative humidity (H-H) | 5 – 90 % |
| Storage temperature (T-T) | -20 – 60 °C |
| Bezel width (bottom) | 17.9 mm |
| Bezel width (side) | 2.4 mm |
| Bezel width (top) | 2.4 mm |
| Depth (without stand) | 37.5 mm |
| Height (without stand) | 294.1 mm |
| Weight (without stand) | 2500 g |
| Width (without stand) | 489.9 mm |
| Package depth | 107 mm |
| Package height | 375 mm |
| Package type | Box |
| Package weight | 3400 g |
| Package width | 556 mm |
| Cables included | HDMI |
| Manual | Yes |
| Power adapter included | Yes |
| Quick start guide | Yes |
| Stand included | Yes |
| Compliance certificates | CE/Electromagnetic Compatibility (EMC)/Low Voltage Directive (LVD) |
| Mean time between failures (MTBF) | 50000 h |
| Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/2291298/fiches?language=EN |
| Energy efficiency class | C |
| EPREL Registration Number | 2291298 |
| EPREL Version Number | 1 |
| Model | DHI-LM22-J200 |
| Unit Calculated Volume | 0.02279 cubm |
| Product Net Weight | 2.5 kg |
| Unit Calculated Weight | 3.4 kg |
| Energy efficiency class (HDR) | Not available |
| Power consumption (off) | 0.3 W |
| Manufacturer Code | DHI-LM22-J200 |
| ELKO Code | 1443241 |
| Warranty | 36 |
