LG 75UH5J-M. Product design: Digital signage flat panel. Display diagonal: 190.5 cm (75″), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: WebOS. Product colour: Black
Laost otsas
Laost otsas
New High Haze UHD Standard Signage
Adequate Brightness Level
The 75UH5J-M series boasts an adequate brightness level of 500 cd/m² for indoor displays, effectively showcasing content and capturing the public’s attention. This makes it an adequate display solution for marketing purposes in various settings, including meeting rooms, airports, retail outlets, and shopping malls.
High-Performance with webOS
LG webOS platform enhances user convenience with intuitive GUI and simple app development tools.
Conformal Coating
In various places the 75UH5J-M series is unable to avoid exposure to environments containing dust, humidity, etc. which may hamper performance over time. The conformal coating on power board reduces these risks by protecting 75UH5J-M series from salt, dust, iron powder, humidity, etc.
IP5x Certified Design
The IP5x Dust-Proof Certification ensures that the product is protected from dust, reducing the risk of performance degradation.
Compatible with AV Control System
The 75UH5J-M series has supported Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*,
boosting business management efficiency.
| Kaal | 41,5 kg |
|---|---|
| Mõõtmed | 5,79 × 168,24 × 96,03 cm |
| Vendor | LG |
| Audio-In | 1 |
| Audio-Out | 1 |
| DVI-D | 1 |
| HDMI | 4 |
| RJ45 | 1 |
| RS232 | 2 |
| USB 2.0 | 1 |
| 600 mm x 400 mm | Yes |
| Depth | 57.9 mm |
| Height | 960.3 mm |
| Width | 1682.4 mm |
| Screen size | 75" |
| Native resolution | 3840×2160 |
| Screen form factor | 16:9 |
| Refresh rate | 120Hz |
| Brightness | 500 |
| Contrast | 1000:1 |
| Dynamic contrast (DCR) | 1000000:1 |
| Response time | 6 ms |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
| Speakers | Yes |
| Power supply | Inbuilt |
| Operation time hours/day | 24/7 |
| Colour | Black |
| Unit Calculated Volume | 0.4688 cubm |
| Product Net Weight | 41.5 kg |
| Unit Calculated Weight | 51.2 kg |
| Summary | LG 75UH5J-M. Product design: Digital signage flat panel. Display diagonal: 190.5 cm (75"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: WebOS. Product colour: Black |
| Colour gamut | 72 % |
| Contrast ratio (dynamic) | 1000000:1 |
| Contrast ratio (typical) | 1000:1 |
| Display brightness | 500 cd/m² |
| Display diagonal | 75 " |
| Display number of colours | 1.07 billion colours |
| Display resolution | 3840 x 2160 pixels |
| Display technology | LCD |
| Haze rate | 28 % |
| HD type | 4K Ultra HD |
| LED backlight | Yes |
| LED backlighting type | Edge-LED |
| Native aspect ratio | 16:9 |
| Native refresh rate | 120 Hz |
| Panel life | 50000 h |
| Panel type | IPS |
| Touchscreen | No |
| DisplayPorts quantity | 1 |
| DVI port | No |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI input ports quantity | 3 |
| HDMI output ports quantity | 1 |
| HDMI ports quantity | 4 |
| Remote (IR) input | 1 |
| RS-232C | Yes |
| USB connector type | USB Type-A |
| USB port | Yes |
| USB ports quantity | 1 |
| USB version | 2.0 |
| Built-in speaker(s) | Yes |
| Bezel width (bottom) | 14.9 mm |
| Bezel width (side) | 14.9 mm |
| Bezel width (top) | 14.9 mm |
| Orientation | Horizontal |
| Panel mounting interface | 600 x 400 mm |
| Placement supported | Indoor |
| Product colour | Black |
| Product design | Digital signage flat panel |
| VESA mounting | Yes |
| Automatic brightness control | Yes |
| HDCP | Yes |
| HDCP version | 1.4/2.2/2.3 |
| On Screen Display (OSD) | Yes |
| Open Pluggable Specification (OPS) | Yes |
| Operating hours (hours/days) | 24/7 |
| Picture-in-Picture | Yes |
| Purpose | Universal |
| AC input frequency | 50-60 Hz |
| AC input voltage | 100-240 V |
| Power consumption (max) | 230 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 170 W |
| Internal memory | 16 GB |
| Operating system installed | WebOS |
| Operating system version | 6.0 |
| Display depth | 57.9 mm |
| Display height | 960.3 mm |
| Display weight | 41500 g |
| Display width | 1682.4 mm |
| Package depth | 228 mm |
| Package height | 1123 mm |
| Package weight | 51200 g |
| Package width | 1816 mm |
| Batteries included | Yes |
| Cables included | AC |
| Remote control included | Yes |
| Operating relative humidity (H-H) | 10 – 80 % |
| Operating temperature (T-T) | 0 – 40 °C |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Real Time Clock (RTC) | Yes |
| Audio output | 1 |
| Plug and Play | Yes |
| Power consumption (PowerSave) | 120 W |
| Manufacturer Code | 75UH5J-M |
| ELKO Code | 1406647 |
| Warranty | 36 |
| Input/Output connectors — Audio-In | 1 |
| Input/Output connectors — Audio-Out | 1 |
| Input/Output connectors — DVI-D | 1 |
| Input/Output connectors — HDMI | 4 |
| Input/Output connectors — RJ45 | 1 |
| Input/Output connectors — RS232 | 2 |
| Input/Output connectors — USB 2.0 | 1 |
| VESA mounting interface — 600 mm x 400 mm | Yes |
| Product Dimensions — Depth | 57.9 mm |
| Product Dimensions — Height | 960.3 mm |
| Product Dimensions — Width | 1682.4 mm |
