Videowall VMB-U
Always-on, space-saving solution with extreme-narrow bezels
See an immersive and dependable viewing experience, 24/7 with Samsung’s VMB-U series. The display’s slim depth and 500 nit brightness ensures highly visible images and legible messages in a wide range of locations from shopping malls to lobbies, meeting rooms, control rooms and more.
| Kaal | 15,7 kg |
|---|---|
| Mõõtmed | 25769,9 × 10221193 × 577719 cm |
| Vendor | SAMSUNG |
| Depth | 69.9 mm |
| Height | 577 mm |
| Width | 1022 mm |
| Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/1192451/fiches?language=EN |
| Energy efficiency class | G |
| EPREL Registration Number | 1192451 |
| EPREL Version Number | 3 |
| Model | VM46B |
| Model name | VM46B |
| Panel type | IPS |
| Response time | 0.008 s |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
| Unit Calculated Volume | 0.2198 cubm |
| Product Net Weight | 15.7 kg |
| Unit Calculated Weight | 21 kg |
| Summary | Samsung VM46B-U. Display diagonal: 116.8 cm (46"), Display resolution: 1920 x 1080 pixels, Display technology: LCD, Display brightness: 500 cd/m², HD type: Full HD, Operating hours (hours/days): 24/7. Product colour: Black |
| Aspect ratio | 16:9 |
| Contrast ratio (dynamic) | 45000:1 |
| Contrast ratio (typical) | 1200:1 |
| Display brightness | 500 cd/m² |
| Display diagonal | 46 " |
| Display resolution | 1920 x 1080 pixels |
| Display technology | LCD |
| HD type | Full HD |
| Horizontal scan range | 62.7 – 72.3 kHz |
| Operating hours (hours/days) | 24/7 |
| Pixel frequency | 82 MHz |
| Pixel pitch | 0.53 x 0.53 mm |
| Vertical scan range | 57 – 63 Hz |
| Bezel width (bottom) | 2.25 mm |
| Bezel width (side) | 1.25 mm |
| Bezel width (top) | 2.25 mm |
| Orientation | Horizontal/Vertical |
| Panel colour | Black |
| Panel mounting interface | 600 x 400 mm |
| Placement supported | Indoor |
| Product colour | Black |
| VESA mounting | Yes |
| Audio input | Yes |
| Audio output | Yes |
| DisplayPort version | 1.2 |
| DisplayPorts quantity | 1 |
| DVI port | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| HDCP | Yes |
| HDCP version | 2.2 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| IR input ports quantity | 1 |
| RS-232 input ports | 1 |
| RS-232 output ports | 1 |
| RS-232C | Yes |
| USB port | Yes |
| USB ports quantity | 1 |
| AC input frequency | 50 – 60 Hz |
| AC input voltage | 100 – 240 V |
| Energy consumption (SDR) per 1000 hours | 128 kWh |
| Energy efficiency class (SDR) | G |
| Energy efficiency scale | A to G |
| Power consumption (typical) | 160 W |
| Harmonized System (HS) code | 85285210 |
| Operating relative humidity (H-H) | 10 – 90 % |
| Operating temperature (T-T) | 0 – 40 °C |
| Certification | FCC (USA) Part 15, Subpart B Class ACE (Europe) : EN55032 : 2012 or 2015 EN55024:2010 or EN 55035:2017VCCI (Japan) : VCCI CISPR32:2016 Class BKCC/EK (Korea) : Tuner : KN13 / KN20Tunerless : KN22 / KN24BSMI (Taiwan) : CNS13438 ( ITE EMI ) Class A / CNS14 |
| Weight | 15700 g |
| Package depth | 257 mm |
| Package height | 719 mm |
| Package weight | 22200 g |
| Package width | 1193 mm |
| Units per Shipping Box | 1 |
| Manufacturer Code | LH46VMBUBGBXEN |
| ELKO Code | 1435291 |
| Warranty | 36 |
| AV-In | 1 |
| AV-out | 1 |
| DisplayPort | 1 |
| HDMI | 2 |
| RJ45 | 1 |
| RS232 | 2 |
| USB 2.0 | 1 |
| 600 mm x 400 mm | Yes |
| Product name | Digital signage LFD |
| Screen size | 46" |
| Native resolution | 1920×1080 |
| Brightness | 500 |
| Contrast | 1200:1 |
| Pixel size | 0.53 mm |
| Operation time hours/day | 24/7 |
| Operating temperature range | 0℃~ 40℃ |
| Battery | AAA x2 |
| Energy consumption, standard | 128 kWh/1000h |
| Power consumption | 160 Watts |
| Standby consumption | 0.5 Watts |
| Included Accessories | Quick Setup Guide Warranty Card Power Cord RS232C(IN) Gender (Stereo to DB-9) Remote Controller + Batteries DP cable |
| Colour | Black |
| Input/Output connectors — AV-In | 1 |
| Input/Output connectors — AV-out | 1 |
| Input/Output connectors — DisplayPort | 1 |
| Input/Output connectors — HDMI | 2 |
| Input/Output connectors — RJ45 | 1 |
| Input/Output connectors — RS232 | 2 |
| Input/Output connectors — USB 2.0 | 1 |
| VESA mounting interface — 600 mm x 400 mm | Yes |
| Product Dimensions — Depth | 257/69.9 mm |
| Product Dimensions — Height | 577/719 mm |
| Product Dimensions — Width | 1022/1193 mm |
| Energy Efficiency — Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/1192451/fiches?language=EN |
| Energy Efficiency — Energy efficiency class | G |
| Energy Efficiency — EPREL Registration Number | 1192451 |
| Energy Efficiency — EPREL Version Number | 3 |
| Display — Aspect ratio | 16:9 |
| Display — Contrast ratio (dynamic) | 45000:1 |
| Display — Contrast ratio (typical) | 1200:1 |
| Display — Display brightness | 500 cd/m² |
| Display — Display diagonal | 46 " |
| Display — Display resolution | 1920 x 1080 pixels |
| Display — Display technology | LCD |
| Display — HD type | Full HD |
| Display — Horizontal scan range | 62.7 – 72.3 kHz |
| Display — Operating hours (hours/days) | 24/7 |
| Display — Panel type | IPS |
| Display — Pixel frequency | 82 MHz |
| Display — Pixel pitch | 0.53 x 0.53 mm |
| Display — Response time | 0.008 s |
| Display — Vertical scan range | 57 – 63 Hz |
| Display — Viewing angle, horizontal | 178 ° |
| Display — Viewing angle, vertical | 178 ° |
| Design — Bezel width (bottom) | 2.25 mm |
| Design — Bezel width (side) | 1.25 mm |
| Design — Bezel width (top) | 2.25 mm |
| Design — Orientation | Horizontal/Vertical |
| Design — Panel colour | Black |
| Design — Panel mounting interface | 600 x 400 mm |
| Design — Placement supported | Indoor |
| Design — Product colour | Black |
| Design — VESA mounting | Yes |
| Ports & interfaces — Audio input | Yes |
| Ports & interfaces — Audio output | Yes |
| Ports & interfaces — DisplayPort version | 1.2 |
| Ports & interfaces — DisplayPorts quantity | 1 |
| Ports & interfaces — DVI port | Yes |
| Ports & interfaces — Ethernet LAN | Yes |
| Ports & interfaces — Ethernet LAN (RJ-45) ports | 1 |
| Ports & interfaces — HDCP | Yes |
| Ports & interfaces — HDCP version | 2.2 |
| Ports & interfaces — HDMI ports quantity | 2 |
| Ports & interfaces — HDMI version | 2.0 |
| Ports & interfaces — IR input ports quantity | 1 |
| Ports & interfaces — RS-232 input ports | 1 |
| Ports & interfaces — RS-232 output ports | 1 |
| Ports & interfaces — RS-232C | Yes |
| Ports & interfaces — USB port | Yes |
| Ports & interfaces — USB ports quantity | 1 |
| Power — AC input frequency | 50 – 60 Hz |
| Power — AC input voltage | 100 – 240 V |
| Power — Energy consumption (SDR) per 1000 hours | 128 kWh |
| Power — Energy efficiency class (SDR) | G |
| Power — Energy efficiency scale | A to G |
| Power — Power consumption (typical) | 160 W |
| Logistics data — Harmonized System (HS) code | 85285210 |
| Operational conditions — Operating relative humidity (H-H) | 10 – 90 % |
| Operational conditions — Operating temperature (T-T) | 0 – 40 °C |
| Sustainability — Certification | FCC (USA) Part 15, Subpart B Class ACE (Europe) : EN55032 : 2012 or 2015 EN55024:2010 or EN 55035:2017VCCI (Japan) : VCCI CISPR32:2016 Class BKCC/EK (Korea) : Tuner : KN13 / KN20Tunerless : KN22 / KN24BSMI (Taiwan) : CNS13438 ( ITE EMI ) Class A / CNS14 |
| Weight & dimensions — Depth | 69.9 mm |
| Weight & dimensions — Height | 577 mm |
| Weight & dimensions — Weight | 15700 g |
| Weight & dimensions — Width | 1022 mm |
| Packaging data — Package depth | 257 mm |
| Packaging data — Package height | 719 mm |
| Packaging data — Package weight | 22200 g |
| Packaging data — Package width | 1193 mm |
